Magnetostrictive Linear Position Sensor

*Robust and reliable, oil and dirt resistant *Non-contact measurement, never wear *Absolute output, no need to return to zero *Easy to diagnose, LED lights show real-time status Modular design, easy to replace *Low-power design, effectively reducing system temperature drift

Send Inquiry

Description

R Serial Magnetostrictive Linear Position Sensor

Technical characteristics

Rugged and fully enclosed design.
Non-wear, non-contact measurement method.
Easy to use, standard analog signal output.
Easy to diagnose, LED indicator status indication.
Stable and reliable, using digital analog technology.
No need to return to zero, absolute position output.
Low power consumption design effectively reduces system heating.
The starting and ending position of measurement can be adjusted in full range.
Multiple interfaces available: Analog, SSI, Profibus-DP, CANopen, Star/Stop, Profinet, EtherCAT, EtherNet/IP.

Technical parameter

Measurement data: position magnet ring

Operating current: < 80mA (varying with range)

Effective stroke: 25 ~ 5500mm, customized according to customer needs

Polarity protection: Maximum-30Vdc

Current: 4 ~ 20mA or 20 ~ 4mA (min/max load 0/500 Ω)

Overpressure protection: Maximum 36Vdc

Voltage: 0 ~ 10Vdc or 0 ~ 5Vdc (minimum load resistance ≥ 10KΩ)

Insulation resistance: > 10MΩ

Nonlinearity: < ± 0.01% of full scale, minimum ± 50μm

Insulation strength: 500V

Repeat accuracy: < ± 0.001% of full scale, minimum ± 1μm

Electronic bin: aluminum alloy

Resolution: 16-bit D/A or 0.0015% of full scale (minimum 1μm)

Measuring rod: 304 stainless steel

Magnet ring speed: arbitrary

Position magnet: standard magnet ring and various ring magnets

Protection level: IP65RP aluminum molded shell

Installation direction: Any direction

Working temperature:-40℃ ~ + 85℃

Outgoing mode: straight cable or aviation plug

Input voltage: + 24Vdc ± 20%

Non-usable area at head and end: 50.8 mm+63. 5mm (customizable)

Materials

Electronic warehouse Aluminum alloy

rod 304Lstainless steel

position magnet magnet ring, open magnet

outer pipe pressure 35MPa(continuous)/70MPa(peak)

Dimension

dimension

Application

Die casting machinery

Vulcanizing machinery

Experimental machinery

Press equipment

how to install it ?

The pressure measuring rod of RH series products can be easily separated from the entire electronic compartment of the sensor (two M4X65 screws), which can be quickly replaced without pressure relief, and the pressure measuring rod can become a permanent part of the oil cylinder.
