Linear Transducer For Hydraulic Cylinder

GB Linear Transducer For Hydraulic Cylinder



Introduction

The magnetostrictive level sensor comes with a mounting flange. Directly mounted on the tank flange with 4 M8 screws. Continuous Level measurement of the diesel tank/fuel tank.



The magnetostrictive level sensor is also called the Magnetostrictive level gauge, or Magnetostrictive level transmitter. The magnetostrictive level sensor is the best choice for water, diesel, and fuel tank level measurement.





Features of Magnetostrictive Position Sensor

1. Flanged electronic compartment, the installation height is only 34mm

2. All stainless steel shell, solid and reliable

3. Fully enclosed electronic warehouse, strong anti-interference ability

4. Non-contact measurement, never wear

5. Absolute output, no need to return to zero

Technical parameter

Structure and Materials

Electronic warehouse                    304 stainless steel

Rod                                                304 stainless steel

mounting flange                           304 stainless steel

outer pipe pressure                      35MPa(continuous)/70MPa(peak)

Working Conditions

  Magnet speed                                      any

  Ambient temperature                          -40℃~+85℃

  Humidity/Dew Point                          humidity90%,no condensation

  Temperature Coefficient                   <±0.007%F.S/℃

  Electrical protection                          IP67 IP68-special customization

Dimension

How does A Magnetostrictive Sensor work?

In a magnetostrictive level transmitter, the sensor circuit excites a pulse current along a waveguide wire, creating a pulsed magnetic field. A float, equipped with permanent magnetic rings, moves along the sensor rod in response to liquid level changes. When the pulsed magnetic field interacts with the float's magnetic field, it generates a torsional wave pulse in the magnetostrictive material at the float's position. This pulse travels back along the waveguide at a fixed speed and is detected by the mechanism, allowing precise measurement of the liquid surface position by calculating the time difference between the pulse current and the torsional wave.

Installation

Package



We pack the sensor with thick paper tube , which is stong enough for long time and long distace delivery. If the working range is too much long for example , more than 3 meters , we will pack it with wooden box .

Delivery



We have 11 years export experience. All the sensors can be delivery all over the world , almost every country. We can delivery by air express , such as DHL , Fedex, UPS, EMS and etc. We also can make delivery  by sea cargo with all the documents and certificate to make custom clearance.

Application



·Plastics machinery

·Fluid Power & Linear Actuators

·Hydraulics and Pneumatics

·Processing machines

·Cylinder displacement measurement
