Tension Compression Load Cell 300t

BRG-219 Tension Compression Load Cell 300t Main Features : Widely used in belt scale, hook scale, hopper scale, mechanical arm, electronic scale and so on High Hardness, Stable Structure And Stable Performance The Appearance Is Polished Smooth, Comfortable And Full In Color Add Shielding Line,...

Send Inquiry

Description

BRG-219 Tension Compression Load Cell 300t

Main Features :

Widely used in belt scale, hook scale, hopper scale, mechanical arm, electronic scale and so on
High Hardness, Stable Structure And Stable Performance
The Appearance Is Polished Smooth, Comfortable And Full In Color
Add Shielding Line, Signal Stability, Anti-Interference, High Tensile Strength
Load cell sensor is widely used in universal material testing machine, scale, hook scale, packaging scale, belt scale, in force tester and other tension and pressure testing instruments as well as automation equipment and testing

Technical Parameters

Model	BRG -219
Capacity	2,5,10,25,40,50,100,200,300 T
Related output	2.0± 0.04MV/V 4.0± 0.04MV/V
Accuracy class	C2
Maxlmum number of verification intervals	2000n max
Minimum load cell verification intervals	E Max/5000 V min
Combined erro	≤ ±0.03 %RO
Creep	0.02 %RO/ 30min
Temperature effect on sensitivity	0.0016 %RO /℃
Temperature effect on zero	0.005%RO /℃
Zero balance	±1.0 %RO
Input resistance	725± 10 Ω
Output resistance	700± 3Ω
Insulation resistance	5000MΩ (50V)
Recommended excitation voltage	8~ 15V
Compensated temperature range	-10 ~+40 ℃
Operating temperature range	-35 ~+80 ℃
Safe overload	150 %RO 120 %RO
Ultimate overload	200 %RO 150 %RO
Load cell material	Alloy steel / stainless steel
Connecting cable	2~25t Φ 5.7X8m 40~300t 5.7X13m
