Miniature In Line Load Cell

The Miniature In line Load Cell have been designed such that their excellent mechanical and measurement properties can be optimally used in a wide range of applications. A Single Point Load Cells is also called Platform Load Cell.

Send Inquiry

Description

BRG812 Miniature In Line Load Cell

Production Introduction

The Miniature In Line Load Cell is actually a device that transforms a weight signal into a measurable electrical signal output. It is made of aluminum alloy, which is not only chemically stable, but also strong and plastic enough and has stable mechanical properties at certain high or low temperatures. It is equipped with an anti-interference cable and sensitive strain gauges with IP65 protection, making it not only highly applicable but also capable of accurately detecting data every time.

Features

The Miniature Load Cells, particularly the BRG812 model, exemplify advanced engineering tailored for precision weighing in constrained environments

Compact Design with Wide Weighing Range

Despite their small size, Miniature Load Cells are engineered to accommodate a diverse range of weights, specifically from 3 kg to 50 kg. This versatility allows them to be effectively utilized in various applications, from delicate laboratory measurements to industrial weighing tasks. Their compact design ensures that they can fit into tight spaces without compromising on performance.

Stability and Ease of Installation

The BRG812 model is designed for stability, ensuring consistent and reliable readings. Its user-friendly installation process allows for rapid deployment, making it an ideal choice for situations where time is of the essence. Even in environments with limited space, the BRG812 can be integrated seamlessly, facilitating quick operational readiness.

Quality Assurance and Longevity

The BRG812 has achieved ISO 9001 quality management system certification and CE certification, underscoring its adherence to rigorous quality standards. This certification not only reflects the reliability of the load cell but also assures users of its safety and efficacy in various applications. Additionally, the load cell is built for longevity, promising an extended service life which enhances its overall cost performance.

20240920120019

Advantages

Since our product is already factory compensated for eccentric loads (according to OIML R60), you can quickly install it and set up a weighing scale with just one unit. It is designed according to the single point type, made of high quality aluminum alloy of aviation standard, and can be used to measure loads from 3 kg to 50 kg with 0.03% R.O. (R.O. = rated output).

Dimension

Electrical Connection

Technical Data

Rated Capacity	3, 6, 10, 15, 20, 30, 40, 50 (kg)
Accuracy Class	B *
Rated Output	2.0±10%mV/V
Zero Balance	±5%R.O.
Input Resistance	405±10Ω
Output Resistance	350±3Ω
Linearlty Error	±0.02%R.O.
Repeatability Error	±0.015%R.O.
Hysteresis Error	±0.015%R.O.
Creep in 30 Min.	±0.03%R.O.
Temp.Effect on Output	±0.03%R.O./10℃
Temp.Effect on Zero	±0.05%R.O./10℃
Compensated Temp.Range	-10－+40℃
Excitation, Recommended	5－12VDC
Excitation, Maximum	18VDC
Operating Temp.Range	-20－+60℃
Safe Overload	150%R.C.
Ultimate Overload	200%R.C.
Insulation Resistance	≥2000MΩ(50VDC)
Cable, Length	ø4mm×0.4m *
Protection Class	IP65
