BRGX-307 Multi Axis Load Cell Product Description Sensitive response and high overall accuracy Two-dimensional force multi-directional force measurement, tension and compression bidirectional force, compact structure, high comprehensive accuracy, good long-term stability, high-quality alloy...

Send Inquiry

Description

BRGX-307 Multi Axis Load Cell

Product Description

Sensitive response and high overall accuracy
Two-dimensional force multi-directional force measurement, tension and compression bidirectional force, compact structure, high comprehensive accuracy, good long-term stability, high-quality alloy steel surface nickel-plated

Technical Parameters


Rated quantitative schedule	Kg	50-1000
Output sensitivity	mV/V	2.0±0.05
Zero point output	%F.S.	±1
Non-linear	%F.S.	0.03
lag	%F.S.	0.03
Repeatability	%F.S.	0.03
Creep (30 min)	%F.S.	0.03
Temperature sensitivity drift	%F.S./10℃	0.03
Zero temperature drift	%F.S./10℃	0.05
Response frequency	Hz	1k
Material		42CrMoA
impedance	Ω	350
Insulation resistance	MΩ/100V DC	≥5000
Use voltage	V	5-15
Operating temperature range	℃	-20-60
Safety overload	%R.C.	150
Extreme overload	%R.C.	200
Cable line specifications	m	Φ5*3m
Cable limit pull force	N	98
TEDS		selectable

Dimension (mm)

product-679-250

product-694-252

Force diagram

product-618-351

X307-5

appliaction

Multi Axis Load Cell can measure force and instantaneous changes on 2 axes (x, y). This product has a wide range of applications, such as automatic control, industrial management, medical testing, automotive press accessories and other control and measurement systems

X307-7

X307-8

FAQ

Q: Can we use our own logo?

A: Yes, we can print your private logo according to your request.

Q: What is a multi axis load cell?

A: A multi-axis sensor (also called a six axis load cell, F/T-sensor, multi-component sensor or multicomponent transducer) measures forces and torques, which occur in more than one spatial direction, as with measurements in x- and y-direction.

Q: What are the advantages of multi-axis machine?

A: Increased Part Accuracy. Multi-axis machining can produce complex parts in a single setup. ... Optimized Production of Complex Parts. ... Long Tool Lifespan. ... Provides a Superior Surface Finish. ... Lowered Labor Costs. ... Reduction of Scrap/Waste. ... Mass Production Capabilities.

Q: How do multiple load cells work?

A: Large-scale and complex weighing systems often require multiple load cells to record accurate measurements. These multiple load cell devices are arranged symmetrically around the corners of the measurement platform. This distributes the weight over a wider physical area
