Analog resistance high precision KTR Potentiometer Position Sensor Spring Loaded
This KTR potentiometer position sensor spring loaded is used to measure linear motion or position of a target. Self return by the spring strength. Stroke lengths are available from 5 to 100 mm. Built-in potentiometric unit is made from conductive plastic with minimum temperature drift. Anodized corrosion resistant housing provides environmetal rating of IP 65.
There are different connect heads available according to different using environment, such as sensor heads, wheel heads and rod heads. The SOP linear position sensor is available with integrated signal converter with 4-20 mA output or 0-5/0-10 VDC output.
It is widely used for most of common occasions, especially for small installation space, such as tension regulating devices, speed control, material automatically conveying system, package machine, printing machine, bottle blowing machine, production line etc.
Technical parameter
Package and Delivery
About us
We have our principle as "Clients' needs come first".
1. Premium goods; we have the skilled workers and equipments to produce high quality goods.
2. Strict QC test; each item will be checked before delivery.
3. Rapid reply; Any inquiry or question will be replied within 24 hours.
4. Fast delivery; we will choose the best suitable shipping carrier to ensure the fast delivery.
5. Competitive price; The offer is factory direct sale price, very competitive.
6. Considerate after-sale service; We offer 1 years' warranty within the right use.
FAQ
1. Can I have a sample to test before bulk order?
A: Yes, of course. We can offer samples but you have to pay for them.
2. Do you have 4-20mA output sensor?
A: Yes, we have. More details please contact me freely.
3. What's the protection class?
A: It's IP65.
