BRG-HX01 Ring Type Load Cell
- High stability
- Can be installed in a small space
- Can be non-standard customized
- Anti-interference signals are stable
- High quality alloy steel
- widely used in automobile compression, automatic assembly, 3C production Product testing, new energy product assembly, medical testing, machine Maker field, mold assembly and other industrial testing, since Field of dynamic equipment and testing.
Technical Parameters
|
|
||
|
Rated quantitative schedule |
Kg |
0-100 |
|
Output sensitivity |
mV/V |
2.0±10% |
|
Zero point output |
%F.S. |
±2 |
|
Non-linear |
%F.S. |
0.5 |
|
lag |
%F.S. |
0.1 |
|
Repeatability |
%F.S. |
0.1 |
|
Creep (30 min) |
%F.S. |
0.1 |
|
Temperature sensitivity drift |
%F.S./10℃ |
0.1 |
|
Zero temperature drift |
%F.S./10℃ |
0.1 |
|
Response frequency |
Hz |
1k |
|
Material |
42CrMoA |
|
|
impedance |
Ω |
350 |
|
Insulation resistance |
MΩ/100V DC |
≥5000 |
|
Use voltage |
V |
5-10 |
|
Operating temperature range |
℃ |
-20-80 |
|
Safety overload |
%R.C. |
120 |
|
Extreme overload |
%R.C. |
150 |
|
Cable line specifications |
m |
Φ2*2m |
|
Cable limit pull force |
N |
98 |
|
TEDS |
selectable |
|
High temperature sensors are available, with a maximum operating temperature of 150℃.
High impedance sensors can be provided with an output impedance of 1000 Ω.
Dimension (mm)
|
Range(kg) |
5 |
10 |
20 |
30 |
50 |
100 |
Force diagram
The hollow force position is the inner ring steps
