BRG-ZX001 Pin Load Cell
Load pins are designed to be installed directly into machines or assemblies, replacing existing non-instrumented shafts or pins. They act as a normal component of the assembly while measuring the forces acting on them. The strain gauges on the load pin detect the deformation caused by the applied force, which is then converted into an electrical signal proportional to the force.
Technical Parameters
|
Rated quantitative schedule |
T |
0-100 |
|
Output sensitivity |
mV/V |
1.0±0.05 |
|
Zero point output |
%F.S. |
±2 |
|
Non-linear |
%F.S. |
0.5 |
|
lag |
%F.S. |
0.5 |
|
Repeatability |
%F.S. |
0.5 |
|
Creep (30 min) |
%F.S. |
0.5 |
|
Temperature sensitivity drift |
%F.S./10℃ |
0.05 |
|
Zero temperature drift |
%F.S./10℃ |
0.05 |
|
Response frequency |
Hz |
1k |
|
Material |
42CrMoA |
|
|
impedance |
Ω |
350 |
|
Insulation resistance |
MΩ/100V DC |
≥5000 |
|
Use voltage |
V |
5-15 |
|
Operating temperature range |
℃ |
-20-80 |
|
Safety overload |
%R.C. |
150 |
|
Extreme overload |
%R.C. |
300 |
|
Cable line specifications |
m |
Φ5*3m |
|
Cable limit pull force |
N |
98 |
|
TEDS |
selectable |
Dimension (mm)
|
Range (T) |
A |
B |
C |
D |
E |
F |
G |
H |
K |
M |
|
2,3,5 |
50 |
180 |
66 |
27 |
4.5 |
6.5 |
32 |
7 |
9 |
3 |
|
7,10 |
60 |
190 |
96 |
14 |
10 |
9 |
33 |
9 |
9 |
5 |
|
10,15 |
65 |
210 |
116 |
14 |
10 |
9 |
32 |
9 |
8 |
5 |
|
20,30 |
80 |
225 |
109 |
20 |
12 |
11 |
40 |
10 |
8 |
6 |
|
40,50,100 |
120 |
275 |
153 |
25 |
14 |
13 |
51 |
15 |
12 |
6 |
Force Diagram
A load pin, also known as a clevis pin or dynamometric axle, is a type of load cell used for measuring force or weight in various applications. It is a rod-shaped sensor with strain gauges bonded on its surface, typically at 45° angles with respect to the axis.
highlighting advantages of pin load cell
Creative idea
Compact and robust design, suitable for harsh environments.
good quality
Can measure tensile, compressive, and off-axis loads.
customized services
Available in various diameters (typically 10-600 mm) and capacities (0.5-100 tons)
Techonical support
Can be customized to specific mechanical requirements (diameter, length, etc.)
Application
Load pins are widely used in diverse applications such as overhead lifting equipment, cranes, winches, test benches, aerospace testing, and force measurement in industrial machinery. Their ability to integrate seamlessly into existing assemblies and measure forces directly makes them a popular choice for force monitoring and overload prevention systems.
Compact Structure
Hollow interface round shaft, compact structure,
It has strong resistance to torsion and bending, and has good long-term stability.Can be customized on site
High Quality Steel
High-quality 42CrMo alloy steel, with high strength and toughness, durable, not easy to rust, high temperature resistance, wear resistance, high strength and toughness, good hardenability, high fatigue limit and multiple impact resistance, low temperature Good impact toughness.
Suitable for harsh environments.
why choose us
competitive price
Factiory direct price , which is reasonable , and we can customize according to your requiry
long warranty
Warranty 12 months , and on line after sale service for the whole life.
quickly response
we will reply your requiry with 24 hours .
Global Shipping
we can arrange delivery to every countries all over the world by air express or by sea.
