BRG61060 Dynamic Rotating Torque Meter
Introduction
Dynamic Rotating Torque Meter is keyed at both ends for easy installation and use, as well as its speed of up to 1800 rpm, measurable speed, and output of positive and negative torque signals. In addition, we have high detection accuracy, stability, interference resistance, and the ability to use without repeated zeroing.
Feature
1.Resistance strain is an integrated product composed of sensitive components and integrated circuits;
2. High precision, stable and reliable performance;
3. It can measure the torque value in both directions and the speed;
4. Connection method: Both ends are keyed
Technical Parameters
parameter | Technical index | parameter | Technical index | |
range | 0.2, 0.3, 0.5, 10, 200, 500, 200, 5000Nm | Response frequency | 100μS | |
Sensitivity | 1.5±10% mV / V | Insulation resistance | ≥5000MΩ/ 100VDC | |
Zero output | ±1% F.S. | Excitation voltage | 10VDC(9-15VDC) | |
Non-linear | ±0.1, 0.3% F.S. | Temperature compensation range | -10 ~ 60℃ | |
Hysteresis | ≤±0.05% F.S. | working temperature | -20 ~ 65℃ | |
Repeatability | ≤±0.05% F.S | Safety overload | 150% F.S. | |
Creep | ≤±0.03% F.S/30min | Extreme overload | 200% F.S. | |
Temperature sensitivity drift | 0.03% F.S. / 10℃ | Cable size | Ø5.2×3m | |
Zero temperature drift | 0.03% F.S. / 10℃ | Electrical connections | red/E+, black/E-, green/S+, white/S- | |
Input resistance | 350, 750±10Ω | Material | Aluminum, stainless steel or alloy steel | |
Output resistance | 350, 700±5Ω | other request | customizable |
Dimension (mm)
Application
1. Test of torque and power of motor, engine, internal combustion engine and other rotary force equipment.
2. Test of torque and power of fan, water pump, gear box, torque wrench.
3. Test of torque and power of railway locomotive, automobile, tractor, airplane, ship, mining machinery.
4. It can be used to detect the torque and power in the sewage treatment system.
5. It can be used to make viscosimeter.
6. It can be used in process industry.
Installation
Package & Delivery
Why choose us ?
FAQ
1. What is the MOQ?
There is no MOQ.
2. What is lead time?
If we have it in stock, we can ship it to you within about 3-5 working days.
If we don’t have it in stock, the lead time will be 10-30 days.
3. What is the payment terms?
T/T, Western Union, L/C,
4. What is the express delivery?
DHL, Fedex, TNT ,EMS, UPS etc.
We will choose the safe and cheapest way for you to reduce your cost.
Economic shipping way: by sea, by air transport
If you place mass order with us, the shipping way of by sea or by air transport will be ideal choice.
5. What is the quality guarantee?
Quality guarantee: 12 months.
If the product has quality problem within 12 months, please return it to us, we will repair it; if we can’t repair it successfully, we will give you a new one; but the man-made damage, improper operation and force majeure will be excepted.
And you will pay the shipping cost of returning to us, we will pay the shipping cost to you.
6. Is there any after-sale service?
After you receive our product, if you have any questions or need any assistance, we can provide you the after-sale service by e-mail,skype,telephone and QQ etc.
