Pull Wire Encoder

5-12 Meters Working Range Pull Wire Encoder EP130 pull wire encoder is a high-precision rope displacement sensor. The output signals of the sensor are: resistance Output, voltage output (0-5V; 0-10V), current output (4-20mA, two-wire or three-wire). (5-12 meters range) Features  Very robust...

Send Inquiry

Description

5-12 Meters Working Range Pull Wire Encoder

long working range wire sensor

EP130 pull wire encoder is a high-precision rope displacement sensor. The output signals of the sensor are: resistance Output, voltage output (0-5V; 0-10V), current output (4-20mA, two-wire or three-wire). (5-12 meters range)

Features:

Very robust construction for mechanical engineering and industrial plant application.
The spindle structure of measuring drum, to ensure measurement accuracy up to 0.15%FS, max speed up to 0.5m/s.
Max measuring range up to 12 meters
Variety of signal output optional: voltage output, push + pull, 4-20mA , resistance , open collector RS485,
Easy to install and to use
Protection class IP65
Usage life is up to 5 million times

Technicla parameter

No,	Range	Output signal	Linear precision	Repeat precision	Rope diameter	Max working spped	I P	Usage temperature	Usage life
s	100 – 2500mm	Resistance	± 0. 15 %	士0. 02%	0. 8mm	1m/s	IP65 (water proof type I P67 )	-40℃-+80℃	5 million times
		0-5v
		0-10V
		4-20MA
		RS485 digital signal	± 0.1%	士0.01%
		Incremental pulse output	± 0.05%	See the Schedule
M	500 - 7500 mm	Resistance	± 0. 15 %	± 0. 02%
		0- 5V
		0-10V
		4-20MA
		RS485 digital signal	± 0.1%	士0.01%
		Incremental pulse output	± 0.05%	See the Schedule
L	7000-12000mm	Resistance	土0 . 15 %	土0. 02%		0 . 5m / s
		0-5V
		0- 10 V
		4-20mA
		RS485 digital signal	± 0.1%	± 0 . 0 1%
		Incremental pulse output	± 0.05%	See the Schedule
XL	120 00- 30000mm	Resistance	土0 . 15 %	土0. 02%
		0-5V
		0 - 10 V
		4-20mA
		RS485 digital signal	± 0.1%	+ 0. 01%
		Incremental pulse output	± 0.05%	See the Schedule
XS	100-1000rrvn	Resistance	± 0. 15 % )	± 0. 02 %		1m/s	IP67
		0-5V(External module)
		0-10V(External module)
		4-20mA (External module
		RS485 (External module)	± 0.1%	士0.01%
xxs	100-600rrrn	Resistance	±0. 15 %	± 0. 02%
		0-5V
		0- 10 V
		4-20mA
		RS485 (External module)	± 0.1%	士0.01%

Dimension

For 5-12 meters working range , the dimension is same .

Wire connection

2022080216465915d09e8244c547019469de5542c379d9

Package

PACKAGE

pack

Application

This pull wire encoder is widely used in the machine industry .

20220807160034ce3b502487ab4ffe95909db65489e1d5

Usage notes

Wrong wiring may damage the sensor
Make sure wire in the power off state
Do not let go after wire is pulled out, otherwise the sensor could be easily damaged
Do not exceed the total length of the wire
Please ensure the cleanness of the equipment and wire line to prolong the service life
Avoid external force
