KTC Linear Displacement Transducer
Description
Stainless steel tie rods inside the linear displacement tansduder for smooth operation. The improved material and structure make the product last longer, and the working temperature is between -40℃ and 80℃. Resistive track connection technology (dual trim technology) ensures product linearity and stability. The product protection level can reach IP65, the operation speed is fast, and the precision is accurate.
Features
1. The straight line engraving machine to make the displacement more accurate.
2. Imported brushes , no wear
3. Long using life, IP65
4. The anodized aluminum alloy shell
5. Excellent performance and excellent linearity.
6. Allows high running speed up to 10 m/s.
7. Available with integrated signal converter with 4-20mA 0-10V or 0-5VDC output.
Technical Specifcations
Measuring stroke | 75-1250mm |
Linearity | ±0.05% |
Repeated | <0.01mm |
Resolution | Infinite |
Resistance | 5KΩ/10KΩ |
Resolution tolerance | ±20% |
Load resistance | >100KΩ |
Allow power supply voltage | 28V |
Displacement speed | <5m/s |
Shell materials | Anodized aluminum |
Rod materials | Stainless steel |
Rod diameter | Φ6mm |
Mechanical fixation | Adjustable |
IP DEGREE | IP65 |
Working temperature | -40℃-80℃ |
Structure
Applications:
Packing details:
♦ Standard package: paper tube,
♦ Tube dimension: 550mm x 55mm x 55mm
♦ Packing methods: each to be wrapped with poly film then to a paper tube
Shipping details:
♦ Air cargo with fast delivery time, such as DHL, FedEx IP, UPS etc; approx 2-7 working days
♦ Special line with economic cost, such as ARAMEX, FedEx IE, UPS Expedited etc; approx 4-9 working days
♦ Sea trasportation with cheap freight; approx 45 days
Why choose us:
1. Any inquiry or question will be replied within 24 hours.
2. Short preparation time after receipt of payment
3. We check every product before shipment.
4. Competitive price, considerate service.
5. Any quality problems , we will follow up until the end.
FAQ
Q1: What's the lead time?
A1: Generally speaking, it's within 5 working days after receipt of payment.
Q2: How long are your products' warranty?
A2: 1 year.
Q3. Can you do the designs for us?
A3: Yes. We can manufacture the products as per your requirements.
